ProLight 1500

   ProLight 1500 module set with LED chips of the latest generation achieve maximum efficiency values and optimum light uniformity. The modules have been specifically developed for use in planar luminaires to replace two parallel 1500mm fluorescent tube (by 4 ProLight 1500-1 and 2 ProLight 1500-2 LED engines in series). The product range covers colour temperatures Warm White 2700K,3000K, Neutral White 4000K and Cold White 5000K, 6000K with CRI > 80 and module efficiency of up to 167 lm/W. The module set is driven by constant current max 1050mA with voltage of max 50V. The design is improved for simple installation and for standard constant current SELV power supplies.

 Benefits:

• Ideal for linear and panel lights
• Perfect for replacing 150cm florescent tube
• Luminous flux range for set 2600 lm – 4000 lm
• Efficacy of the module up to 167 lm/W
• High colour rendering index CRI > 80
• Small colour tolerance (MacAdam 3)
• Small luminous flux tolerances
• Colour temperatures from 2700K to 6500K
• Good uniform light, when several LED modules are used in a line
• Samsung high efficiency LED chips
• Push terminals for quick and simple wiring of LED module to LED module
• Simple installation (e.g. screws)
• Long life-time: 50,000 hours

Technical Specification:

ProLight 1500	Color Temperature K	Typ. luminous flux at tj = 25 °C	Typ. Voltage at tj = 25 °C	Typ. power consumption at tj = 25 °C	Luminous efficacy module at tj = 25 °C	Colour rendering index CRI
ProLight 1500-1 Operating mode High Efficiency at constant current 700mA	3000 K	977 Lm	8.91 V	6.24 W	157 Lm/W	>80
	4000 K	1008 Lm	8.91 V	6.24 W	162 Lm/W	>80
	5000 K	1040 Lm	8.91 V	6.24 W	167 Lm/W	>80
ProLight 1500-1 Operating mode High Output at constant current 1050mA	3000 K	1414 Lm	9.3 V	9.77 W	145 Lm/W	>80
	4000 K	1459 Lm	9.3 V	9.77 W	149 Lm/W	>80
	5000 K	1505 Lm	9.3 V	9.77 W	154 Lm/W	>80
ProLight 1500-2 Operating mode High Efficiency at constant current 700mA	3000 K	651 Lm	5.94 V	4.16 W	156 Lm/W	>80
	4000 K	672 Lm	5.94 V	4.16 W	162 Lm/W	>80
	5000 K	693 Lm	5.94 V	4.16 W	167 Lm/W	>80
ProLight 1500-2 Operating mode High Output at constant current 1050mA	3000 K	943 Lm	6.2 V	6.51 W	145 Lm/W	>80
	4000 K	973 Lm	6.2 V	6.51 W	149 Lm/W	>80
	5000 K	1003 Lm	6.2 V	6.51 W	154 Lm/W	>80
