EMILI

EMILI module with LED chips of the latest generation achieve maximum efficiency values and optimum light uniformity. The product range covers colour temperatures Warm White 2700K, 3000K, Neutral White 4000K and Cold White 5000K, 6000K with CRI > 80 and module efficiency of up to 185 lm/W. The module is driven by constant current max 455mA/1050mA with voltage of max 19.2V. The design is improved for simple installation.

Benefits:

Luminous flux range from 696 lm – 1917 lm
Efficacy of the module up to 185 lm/W
High colour rendering index CRI > 80
Small colour tolerance (MacAdam 3)
Small luminous flux tolerances
Colour temperatures from 2700K to 6500K
Push terminals for quick and simple wiring of LED module to LED module
Simple installation (e.g. screws)
Long life-time: 40,000 hours

Technical Specification:

EMILI	Color Temperature K	Typ. luminous flux at tj = 25 °C	Typ. Voltage at tj =25 °C	Typ. power consumption at tj = 25 °C	Luminous efficacy module at tj = 25 °C	Colour rendering index CRI
Module Low cost Efficiency at constant current 455mA	3000 K	696 Lm	18 V	4.7 W	148 Lm/W	>80
	4000 K	744 Lm	18 V	4.7 W	158 Lm/W	>80
	5000 K	768 Lm	18 V	4.7 W	163 Lm/W	>80
Module High Output at constant current 1050mA	3000 K	1471 Lm	19.2 V	11.5 W	128 Lm/W	>80
	4000 K	1519 Lm	19.2 V	11.5 W	132 Lm/W	>80
	5000 K	1567 Lm	19.2 V	11.5 W	136 Lm/W	>80
Module High Efficiency at constant current 455mA	3000 K	744 Lm	17.7 V	4.6 W	162 Lm/W	>80
	4000 K	792 Lm	17.7 V	4.6 W	172 Lm/W	>80
	5000 K	852 Lm	17.7 V	4.6 W	185 Lm/W	>80
Module High Efficiency and High Output at constant current 1050mA	3000 K	1674 Lm	18.9 V	11.3 W	148 Lm/W	>80
	4000 K	1782 Lm	18.9 V	11.3 W	158 Lm/W	>80
	5000 K	1917 Lm	18.9 V	11.3 W	170 Lm/W	>80
