ProLight 600

   ProLight 600 module with LED chips of the latest generation achieve maximum efficiency values and optimum light uniformity. The modules have been specifically developed for use in planar luminaires to replace single 1200mm fluorescent tube (by 2 LED engines in series). The product range covers colour temperatures Warm White 2700K, 3000K, Neutral White 4000K and Cold White 5000K, 6000K with CRI > 80 and module efficiency of up to 167 lm/W. The module is driven by constant current max 700mA with voltage of max 23V. The design is improved for simple installation.

 Benefits:

  • Ideal for linear and panel lights
  • Perfect for replacing single 600/1200mm florescent tube
  • Luminous flux range from 1140 – 2280 lm
  • Efficacy of the module up to 167 lm/W
  • High colour rendering index CRI > 80
  • Small colour tolerance (MacAdam 3)
  • Small luminous flux tolerances
  • Colour temperatures from 2700K to 6500K
  • Good uniform light, when several LED modules are used together in a line
  • Samsung high efficiency LED chips
  • Push terminals for quick and simple wiring of LED module to LED module
  • Simple installation (e.g. screws)
  • Long life-time: 50,000 hours



Technical Specification:

ProLight 600

Color Temperature
K

Typ. luminous flux
at tj = 25 °C

Typ. Voltage
at tj =25 °C

Typ. power consumption
at tj = 25 °C

Luminous efficacy module
at tj = 25 °C

Colour rendering index
CRI

Operating mode High Efficiency
at constant current 350mA

3000 K

1139 Lm

20.8 V

7.28 W

156 Lm/W

>80

4000 K

1176 Lm

20.8 V

7.28 W

161 Lm/W

>80

5000 K

1213 Lm

20.8 V

7.28 W

167 Lm/W

>80

Operating mode High Output
at constant current 700mA

3000 K

2148 Lm

22.7 V

15.89 W

135 Lm/W

>80

4000 K

2217 Lm

22.7 V

15.89 W

139 Lm/W

>80

5000 K

2287 Lm

22.7 V

15.89 W

144 Lm/W

>80
